Features:
• Dual independent random voltage channels (±10V, 16-bit resolution)
• Stepped and smooth random voltage generation with continuous Slope morphing
• Shapeable transitions with Bezier, exponential, and arc/peak curve families
• Per-channel loop capture: replay a selectable window of recorded history (16 or 32 steps)
• Live-adjustable Start and Length controls for real-time pattern reshaping
• Probability control for conditional value generation, with Swing for clock humanization
• Per-channel Lock: freeze Slope, Shape, and Prob settings independently
• Per-channel Level and Offset control
• CV inputs for Clock, Slope, Shape, and Probability
• Automatic external clock sync, no manual switching required
• Per-channel logic outputs, selectable as gate or trigger
• Clock output following the active timing source
• State save/recall across power cycles
• 12HP, 42mm depth (skiff friendly), 75mA +12V / 35mA -12V
